Wed, 05 Jun 2019

Styling GTK3 in Python with CSS

Lately I've been running with my default python set to Python 3. Debian still uses Python 2 as the default, which is reasonable, but adding a ~/bin/python symlink to /usr/bin/python3 helps me preview scripts that might become a problem once Debian does switch. I thought I had converted most of my Python scripts to Python 3 already, but this link is catching some I didn't convert.

Python has a nice script called 2to3 that can convert the bulk of most scripts with little fanfare. The biggest hassles that 2to3 can't handle are network related (urllib and urllib2) and, the big one, user interfaces. PyGTK, based on GTK2 has no Python 3 equivalent; in Python 3, the only option is to use GObject Introspection (gi) and GTK3. Since there's almost no documentation on python-gi and gtk3, converting a GTK script always involves a lot of fumbling and guesswork.

A few days ago I tried to play an MP3 in my little musicplayer.py script and discovered I'd never updated it. I have enough gi/GTK3 scripts by now that I thought something with such a simple user interface would be easy. Shows how much I know about GTK3!

I got the basic window ported pretty easily, but it looked terrible: huge margins everywhere, and no styling on the text, like the bold, large-sized text I had previously use to highlight the name of the currently playing song. I tried various approaches, but a lot of the old methods of styling have been deprecated in GTK3; you're supposed to use CSS. Except, of course, there's no documentation on it, and it turns out the CSS accepted by GTK3 is a tiny subset of the CSS you can use in HTML pages, but what the subset is doesn't seem to be documented anywhere.

How to Apply a Stylesheet

The first task was to get any CSS at all working. The GNOME Journal: Styling GTK with CSS was helpful in getting started, but had a lot of information that doesn't work (perhaps it did once). At least it gave me this basic snippet:

    css = '* { background-color: #f00; }'
    css_provider = gtk.CssProvider()
    css_provider.load_from_data(css)
    context = gtk.StyleContext()
    screen = Gdk.Screen.get_default()
    context.add_provider_for_screen(screen, css_provider,
                                    gtk.STYLE_PROVIDER_PRIORITY_APPLICATION)

Built-in Class Names

Great! if all you want to do is turn the whole app red. But in reality, you'll want to style different widgets differently. At least some classes have class names:

    css = 'button { background-color: #f00; }'
I found other pages suggesting using 'GtkButton in CSS, but that didn't work for me. How do you find the right class names? No idea, I never found a reference for that. Just guess, I guess.

User-set Class Names

What about classes -- for instance, make all the buttons in a ButtonBox white? You can add classes this way:

    button_context = button.get_style_context()
    button_context.add_class("whitebutton")

If you need to change a class (for instance, turn a red button green), first remove the old class:

    button_context = button.get_style_context()
    entry_style_context.remove_class("red")

Widget Names, like CSS ID

For single widgets, you can give the widget a name and use it like an ID in CSS. Like this:

    label = gtk.Label()
    label.set_use_markup(True)
    label.set_line_wrap(True)
    label.set_name("red_label")
    mainbox.pack_start(label, False, False, 0)
    css = '#red_label { background-color: #f00; }'
[ ... ]

Properties You Can Set

There is, amazingly, a page on which CSS properties GTK3 supports. That page doesn't mention it, but some properties like :hover are also supported. So you can write CSS tweaks like

.button { border-radius: 15; border-width: 2; border-style: outset; }
.button:hover { background: #dff; border-color: #8bb; }

And descendants work, so you can say somthing like

    buttonbox = gtk.ButtonBox(spacing=4)
    buttonbox.set_name("buttonbox")
    mainbox.pack_end(buttonbox, False, False, 0)

    btn = gtk.Button(label="A")
    buttonbox.add(btn)

    btn = gtk.Button(label="B")
    buttonbox.add(btn)
and then use CSS that affects all the buttons inside the buttonbox:
#buttonbox button { color: red; }

No mixed CSS Inside Labels

My biggest disappointment was that I couldn't mix styles inside a label. You can't do something like

label.set_label('Headline'
                'Normal text')

and expect to style the different parts separately. You can use very simple markup like <b>bold</b> normal, but anything further gives errors like "error parsing markup: Attribute 'class' is not allowed on the <span> tag" (you'll get the same error if you try "id"). I had to make separate GtkLabels for each text size and style I wanted, which is a lot more work. If you wanted to mix styles and have them reflow as the content length changed, I don't know how (or if) you could do it.

Fortunately, I don't strictly need that for this little app. So for now, I'm happy to have gotten this much working.

Tags: , , ,
[ 14:49 Jun 05, 2019    More programming | permalink to this entry | comments ]

Thu, 30 May 2019

Plotting a Sequence of Graphs in Matplotlib 3D

A friend and I were talking about temperature curves: specifically, the way the temperature sinks in the evening but then frequently rises again before it really starts cooling off.

I thought it would be fun to plot the curve of temperature as a function of time over successive days, as a 3-D plot. I knew matplotlib had a way to do 3D plots, but I've never actually generated one.

Well, it turns out there are lots of examples, but they all start by generating mysterious data blobs, and none of them explain the structure of the data they're using, and the documentation has mysterious parameters like "zs" that aren't explained anywhere. So getting something that worked was a fiddly process. Creating a color version, to distinguish the graphs better, was even more fiddly.

[Plotting a series of graphs using matplotlib 3d] So I wrote an example that I hope will make it a little clearer for anyone trying to use this library. It can plot using just lines:

[Plotting a series of graphs using matplotlib 3d, color option] ... or it can plot in color, cycling colors manually because by default matplotlib makes adjacent colors similar, exactly the opposite of what you'd want:

Here's the demo: multiplot3d.py on GitHub.

... Except there's a Bug

All is not perfect. Axes3D gets a bit confused sometimes about which layer is supposed to be in front of which other layer. You can see that on the two plots: in both cases, the fourth and fifth layers from the front are reversed, so the fifth layer is drawn in front of the fourth layer. I haven't yet found anyone in the matplotlib organization who seems to know much about Axes3D; eventually I'll file a bug but I want to write a shorter, clearer test case to illustrate the problem. Still, even with the bugs it's a useful technique to know.

Tags: , , ,
[ 09:57 May 30, 2019    More programming | permalink to this entry | comments ]

Fri, 18 Jan 2019

Python: Find Your System's Biggest CPU Hogs

My machine has recently developed an overheating problem. I haven't found a solution for that yet -- you'd think Linux would have a way to automatically kill or suspend processes based on CPU temperature, but apparently not -- but my investigations led me down one interesting road: how to write a Python script that finds CPU hogs.

The psutil module can get a list of processes with psutil.process_iter(), which returns Process objects that have a cpu_percent() call. Great! Except it always returns 0.0, even for known hogs like Firefox, or if you start up a VLC and make it play video scaled to the monitor size.

That's because cpu_percent() needs to run twice, with an interval in between: it records the elapsed run time and sees how much it changes. You can pass an interval to cpu_percent() (the units aren't documented, but apparently they're seconds). But if you're calling it on more than one process -- as you usually will be -- it's better not to wait for each process. You have to wait at least a quarter of a second to get useful numbers, and longer is better. If you do that for every process on the system, you'll be waiting a long time.

Instead, use cpu_percent() in non-blocking mode. Pass None as the interval (or leave it blank since None is the default), then loop over the process list and call proc.cpu_percent(None) on each process, throwing away the results the first time. Then sleep for a while and repeat the loop: the second time, cpu_percent() will give you useful numbers.

def hoglist(delay=5):
    '''Return a list of processes using a nonzero CPU percentage
       during the interval specified by delay (seconds),
       sorted so the biggest hog is first.
    '''
    proccesses = list(psutil.process_iter())
    for proc in proccesses:
        proc.cpu_percent(None)    # non-blocking; throw away first bogus value

    print("Sleeping ...")
    sys.stdout.flush()
    time.sleep(delay)
    print()

    procs = []
    for proc in proccesses:
        percent = proc.cpu_percent(None)
        if percent:
            procs.append((proc.name(), percent))

    print(procs)
    procs.sort(key=lambda x: x[1], reverse=True)
    return procs

if __name__ == '__main__':
    prohogscs = hoglist()
    for p in hogs:
        print("%20s: %5.2f" % p)

It's a useful trick. Though actually applying this to a daemon that responds to temperature, to solve my overheating problem, is more complicated. For one thing, you need rules about special processes. If your Firefox goes wonky and starts making your X server take lots of CPU time, you want to suspend Firefox, not the X server.

Tags: , ,
[ 15:54 Jan 18, 2019    More programming | permalink to this entry | comments ]

Sun, 23 Sep 2018

Writing Solar System Simulations with NAIF SPICE and SpiceyPy

Someone asked me about my Javascript Jupiter code, and whether it used PyEphem. It doesn't, of course, because it's Javascript, not Python (I wish there was something as easy as PyEphem for Javascript!); instead it uses code from the book Astronomical Formulae for Calculators by Jean Meeus. (His better known Astronomical Algorithms, intended for computers rather than calculators, is actually harder to use for programming because Astronomical Algorithms is written for BASIC and the algorithms are relatively hard to translate into other languages, whereas Astronomical Formulae for Calculators concentrates on explaining the algorithms clearly, so you can punch them into a calculator by hand, and this ends up making it fairly easy to implement them in a modern computer language as well.)

Anyway, the person asking also mentioned JPL's page HORIZONS Ephemerides page, which I've certainly found useful at times. Years ago, I tried emailing the site maintainer asking if they might consider releasing the code as open source; it seemed like a reasonable request, given that it came from a government agency and didn't involve anything secret. But I never got an answer.

[SpiceyPy example: Cassini's position] But going to that page today, I find that code is now available! What's available is a massive toolkit called SPICE (it's all in capitals but there's no indication what it might stand for. It comes from NAIF, which is NASA's Navigation and Ancillary Information Facility).

SPICE allows for accurate calculations of all sorts of solar system quantities, from the basic solar system bodies like planets to all of NASA's active and historical public missions. It has bindings for quite a few languages, including C. The official list doesn't include Python, but there's a third-party Python wrapper called SpiceyPy that works fine.

The tricky part of programming with SPICE is that most of the code is hidden away in "kernels" that are specific to the objects and quantities you're calculating. For any given program you'll probably need to download at least four "kernels", maybe more. That wouldn't be a problem except that there's not much help for figuring out which kernels you need and then finding them. There are lots of SPICE examples online but few of them tell you which kernels they need, let alone where to find them.

After wrestling with some of the examples, I learned some tricks for finding kernels, at least enough to get the basic examples working. I've collected what I've learned so far into a new GitHub repository: NAIF SPICE Examples. The README there explains what I know so far about getting kernels; as I learn more, I'll update it.

SPICE isn't easy to use, but it's probably much more accurate than simpler code like PyEphem or my Meeus-based Javascript code, and it can calculate so many more objects. It's definitely something worth knowing about for anyone doing solar system simulations.

Tags: , ,
[ 16:43 Sep 23, 2018    More programming | permalink to this entry | comments ]

Thu, 24 May 2018

Google Maps API No Longer Free?

A while ago I wrote an interactive trail map page for the PEEC nature center website. At the time, I wanted to use an open library, like OpenLayers or Leaflet; but there were no good sources of satellite/aerial map tiles at the time. The only one I found didn't work because they had a big blank area anywhere near LANL -- maybe because of the restricted airspace around the Lab. Anyway, I figured people would want a satellite option, so I used Google Maps instead despite its much more frustrating API.

This week we've been working on converting the website to https. Most things went surprisingly smoothly (though we had a lot more absolute URLs in our pages and databases than we'd realized). But when we got through, I discovered the trail map was broken. I'm still not clear why, but somehow the change from http to https made Google's API stop working. In trying to fix the problem, I discovered that Google's map API may soon cease to be free:

New pricing and product changes will go into effect starting June 11, 2018. For more information, check out the Guide for Existing Users.

That has a button for "Transition Tool" which, when you click it, won't tell you anything about the new pricing structure until you've already set up a billing account. Um ... no thanks, Google.

Googling for google maps api billing led to a page headed "Pricing that scales to fit your needs", which has an elaborate pricing structure listing a whole bnch of variants (I have no idea which of these I was using), of which the first $200/month is free. But since they insist on setting up a billing account, I'd probably have to give them a credit card number -- which one? My personal credit card, for a page that isn't even on my site? Does the nonprofit nature center even have a credit card? How many of these API calls is their site likely to get in a month, and what are the chances of going over the limit?

It all rubbed me the wrong way, especially when the context of "Your trail maps page that real people actually use has broken without warning, and will be held hostage until you give usa credit card number". This is what one gets for using a supposedly free (as in beer) library that's not Free open source software.

So I replaced Google with the excellent open source Leaflet library, which, as a bonus, has much better documentation than Google Maps. (It's not that Google's documentation is poorly written; it's that they keep changing their APIs, but there's no way to tell the dozen or so different APIs apart because they're all just called "Maps", so when you search for documentation you're almost guaranteed to get something that stopped working six years ago -- but the documentation is still there making it look like it's still valid.) And I was happy to discover that, in the time since I originally set up the trailmap page, some open providers of aerial/satellite map tiles have appeared. So we can use open source and have a satellite view.

Our trail map is back online with Leaflet, and with any luck, this time it will keep working. PEEC Los Alamos Area Trail Map.

Tags: , , ,
[ 16:13 May 24, 2018    More programming | permalink to this entry | comments ]

Mon, 14 May 2018

Plotting the Jet Stream, or Other Winds, with ECMWF Data

I've been trying to learn more about weather from a friend who used to work in the field -- in particular, New Mexico's notoriously windy spring. One of the reasons behind our spring winds relates to the location of the jet stream. But I couldn't find many good references showing how the jet stream moves throughout the year. So I decided to try to plot it myself -- if I could find the data. Getting weather data can surprisingly hard.

In my search, I stumbled across Geert Barentsen's excellent Annual variations in the jet stream (video). It wasn't quite what I wanted -- it shows the position of the jet stream in December in successive years -- but the important thing is that he provides a Python script on GitHub that shows how he produced his beautiful animation.

[Sample jet steam image]

Well -- mostly. It turns out his data sources are no longer available, and he didn't go into a lot of detail on where he got his data, only saying that it was from the ECMWF ERA re-analysis model (with a link that's now 404). That led me on a merry chase through the ECMWF website trying to figure out which part of which database I needed. ECMWF has lots of publically available databases (and even more) and they even have Python libraries to access them; and they even have a lot of documentation, but somehow none of the documentation addresses questions like which database includes which variables and how to find and fetch the data you're after, and a lot of the sample code doesn't actually work. I ended up using the "ERA Interim, Daily" dataset and requesting data for only specific times and only the variables and pressure levels I was interested in. It's a great source of data once you figure out how to request it.

Sign up for an ECMWF API Key

Access ECMWF Public Datasets (there's also Access MARS and I'm not sure what the difference is), which has links you can click on to register for an API key.

Once you get the email with your initial password, log in using the URL in the email, and change the password. That gave me a "next" button that, when I clicked it, took me to a page warning me that the page was obsolete and I should update whatever bookmark I had used to get there. That page also doesn't offer a link to the new page where you can get your key details, so go here: Your API key. The API Key page gives you some lines you can paste into ~/.ecmwfapirc.

You'll also have to accept the license terms for the databases you want to use.

Install the Python API

That sets you up to use the ECMWF api. They have a Web API and a Python library, plus some other Python packages, but after struggling with a bunch of Magics tutorial examples that mostly crashed or couldn't find data, I decided I was better off sticking to the basic Python downloader API and plotting the results with Matplotlib.

The Python data-fetching API works well. To install it, activate your preferred Python virtualenv or whatever you use for pip packages, then run the pip command shown at Web API Downloads (under "Click here to see the installation/update instructions..."). As always with pip packages, you'll have to decide on a Python version (they support both 2 and 3) and whether to use a virtualenv, the much-disrecommended sudo pip, pip3, etc. I used pip3 in a virtualenv and it worked fine.

Specify a dataset and parameters

That's great, but how do you know which dataset you want to load?

There doesn't seem to be anything that just lists which datasets have which variables. The only way I found is to go to the Web API page for a particular dataset to see the form where you can request different variables. For instance, I ended up using the "interim-full-daily" database, where you can choose date ranges and lists of parameters. There are more choices in the sidebar: for instance, clicking on "Pressure levels" lets you choose from a list of barometric pressures ranging from 1000 all the way down to 1. No units are specified, but they're millibars, also known as hectoPascals (hPa): 1000 is more or less the pressure at ground level, 250 is roughly where the jet stream is, and Los Alamos is roughly at 775 hPa (you can find charts of pressure vs. altitude on the web).

When you go to any of the Web API pages, it will show you a dialog suggesting you read about Data retrieval efficiency, which you should definitely do if you're expecting to request a lot of data, then click on the details for the database you're using to find out how data is grouped in "tape files". For instance, in the ERA-interim database, tapes are grouped by date, so if you're requesting multiple parameters for multiple months, request all the parameters for a given month together, rather than making one request for level 250, another request for level 1000, etc.

Once you've checked the boxes for the data you want, you can fetch the data via the web interface, or click on "View the MARS request" to get parameters you can plug into a Python script.

If you choose the Python script option as I did, you can start with the basic data retrieval example. Use the second example, the one that uses 'format' : "netcdf", which will (eventually) give you a file ending in .nc.

Requesting a specific area

You can request only a limited area,

"area": "75/-20/10/60",
but they're not very forthcoming on the syntax of that, and it's particularly confusing since "75/-20/10/60" supposedly means "Europe". It's hard to figure how those numbers as longitudes and latitudes correspond to Europe, which doesn't go down to 10 degrees latitude, let alone -20 degrees. The Post-processing keywords page gives more information: it's North/West/South/East, which still makes no sense for Europe, until you expand the Area examples tab on that page and find out that by "Europe" they mean Europe plus Saudi Arabia and most of North Africa.

Using the data: What's in it?

Once you have the data file, assuming you requested data in netcdf format, you can parse the .nc file with the netCDF4 Python module -- available as Debian package "python3-netcdf4", or via pip -- to read that file:

import netCDF4

data = netCDF4.Dataset('filename.nc')

But what's in that Dataset? Try running the preceding two lines in the interactive Python shell, then:

>>> for key in data.variables:
...   print(key)
...
longitude
latitude
level
time
w
vo
u
v

You can find out more about a parameter, like its units, type, and shape (array dimensions). Let's look at "level":

>>> data['level']
<class 'netCDF4._netCDF4.Variable'>
int32 level(level)
    units: millibars
    long_name: pressure_level
unlimited dimensions:
current shape = (3,)
filling on, default _FillValue of -2147483647 used

>>> data['level'][:]
array([ 250,  775, 1000], dtype=int32)

>>> type(data['level'][:])
<class 'numpy.ndarray'>

Levels has shape (3,): it's a one-dimensional array with three elements: 250, 775 and 1000. Those are the three levels I requested from the web API and in my Python script). The units are millibars.

More complicated variables

How about something more complicated? u and v are the two components of wind speed.

>>> data['u']
<class 'netCDF4._netCDF4.Variable'>
int16 u(time, level, latitude, longitude)
    scale_factor: 0.002161405503194121
    add_offset: 30.095301438361684
    _FillValue: -32767
    missing_value: -32767
    units: m s**-1
    long_name: U component of wind
    standard_name: eastward_wind
unlimited dimensions: time
current shape = (30, 3, 241, 480)
filling on
u (v is the same) has a shape of (30, 3, 241, 480): it's a 4-dimensional array. Why? Looking at the numbers in the shape gives a clue. The second dimension has 3 rows: they correspond to the three levels, because there's a wind speed at every level. The first dimension has 30 rows: it corresponds to the dates I requested (the month of April 2015). I can verify that:
>>> data['time'].shape
(30,)

Sure enough, there are 30 times, so that's what the first dimension of u and v correspond to. The other dimensions, presumably, are latitude and longitude. Let's check that:

>>> data['longitude'].shape
(480,)
>>> data['latitude'].shape
(241,)

Sure enough! So, although it would be nice if it actually told you which dimension corresponded with which parameter, you can probably figure it out. If you're not sure, print the shapes of all the variables and work out which dimensions correspond to what:

>>> for key in data.variables:
...   print(key, data[key].shape)

Iterating over times

data['time'] has all the times for which you have data (30 data points for my initial test of the days in April 2015). The easiest way to plot anything is to iterate over those values:

    timeunits = JSdata.data['time'].units
    cal = JSdata.data['time'].calendar
    for i, t in enumerate(JSdata.data['time']):
        thedate = netCDF4.num2date(t, units=timeunits, calendar=cal)

Then you can use thedate like a datetime, calling thedate.strftime or whatever you need.

So that's how to access your data. All that's left is to plot it -- and in this case I had Geert Barentsen's script to start with, so I just modified it a little to work with slightly changed data format, and then added some argument parsing and runtime options.

Converting to Video

I already wrote about how to take the still images the program produces and turn them into a video: Making Videos (that work in Firefox) from a Series of Images.

However, it turns out ffmpeg can't handle files that are named with timestamps, like jetstream-2017-06-14-250.png. It can only handle one sequential integer. So I thought, what if I removed the dashes from the name, and used names like jetstream-20170614-250.png with %8d? No dice: ffmpeg also has the limitation that the integer can have at most four digits.

So I had to rename my images. A shell command works: I ran this in zsh but I think it should work in bash too.

cd outdir
mkdir moviedir

i=1
for fil in *.png; do
  newname=$(printf "%04d.png" $i)
  ln -s ../$fil moviedir/$newname
  i=$((i+1))
done

ffmpeg -i moviedir/%4d.png -filter:v "setpts=2.5*PTS" -pix_fmt yuv420p jetstream.mp4
The -filter:v "setpts=2.5*PTS" controls the delay between frames -- I'm not clear on the units, but larger numbers have more delay, and I think it's a multiplier, so this is 2.5 times slower than the default.

When I uploaded the video to YouTube, I got a warning, "Your videos will process faster if you encode into a streamable file format." I then spent half a day trying to find a combination of ffmpeg arguments that avoided that warning, and eventually gave up. As far as I can tell, the warning only affects the 20 seconds or so of processing that happens after the 5-10 minutes it takes to upload the video, so I'm not sure it's terribly important.

Results

Here's a video of the jet stream from 2012 to early 2018, and an earlier effort with a much longer 6.0x delay.

And here's the script, updated from the original Barentsen script and with a bunch of command-line options to let you plot different collections of data: jetstream.py on GitHub.

Tags: , , ,
[ 14:18 May 14, 2018    More programming | permalink to this entry | comments ]

Fri, 27 Apr 2018

Displaying PDF with Python, Qt5 and Poppler

I had a need for a Qt widget that could display PDF. That turned out to be surprisingly hard to do. The Qt Wiki has a page on Handling PDF, which suggests only two alternatives: QtPDF, which is C++ only so I would need to write a wrapper to use it with Python (and then anyone else who used my code would have to compile and install it); or Poppler. Poppler is a common library on Linux, available as a package and used for programs like evince, so that seemed like the best route.

But Python bindings for Poppler are a bit harder to come by. I found a little one-page example using Poppler and Gtk3 via gi.repository ... but in this case I needed it to work with a Qt5 program, and my attempts to translate that example to work with Qt were futile. Poppler's page.render(ctx) takes a Cairo context, and Cairo is apparently a Gtk-centered phenomenon: I couldn't find any way to get a Cairo context from a Qt5 widget, and although I found some web examples suggesting renderToImage(), the Poppler available in gi.repository doesn't have that function.

But it turns out there's another Poppler: popplerqt5, available in the Debian package python3-poppler-qt5. That Poppler does have renderToImage, and you can take that image and paint it in a paint() callback or turn it into a pixmap you can use with a QLabel. Here's the basic sequence:

    document = Poppler.Document.load(filename)
    document.setRenderHint(Poppler.Document.TextAntialiasing)
    page = document.page(pageno)
    img = self.page.renderToImage(dpi, dpi)

    # Use the rendered image as the pixmap for a label:
    pixmap = QPixmap.fromImage(img)
    label.setPixmap(pixmap)

The line to set text antialiasing is not optional. Well, theoretically it's optional; go ahead, try it without that and see for yourself. It's basically unreadable.

Of course, there are plenty of other details to take care of. For instance, you can get the size of the rendered image:

    size = page.pageSize()
... after which you can use size.width() and size.height(). They're in points. There are 72 points per inch, so calculate accordingly in the dpi values you pass to renderToImage if you're targeting a specific DPI or need it to fit in a specific window size.

Window Resize and Efficient Rendering

Speaking of fitting to a window size, I wanted to resize the content whenever the window was resized, which meant redefining resizeEvent(self, event) on the widget. Initially my PDFWidget inherited from Qwidget with a custom paintEvent(), like this:

        # Create self.img once, early on:
        self.img = self.page.renderToImage(self.dpi, self.dpi)

    def paintEvent(self, event):
        qp = QPainter()
        qp.begin(self)
        qp.drawImage(QPoint(0, 0), self.img)
        qp.end()
(Poppler also has a function page.renderToPainter(), but I never did figure out how to get it to do anything useful.)

That worked, but when I added resizeEvent I got an infinite loop: paintEvent() called resizeEvent() which triggered another paintEvent(), ad infinitum. I couldn't find a way around that (GTK has similar problems -- seems like nearly everything you do generates another expose event -- but there you can temporarily disable expose events while you're drawing). So I rewrote my PDFWidget class to inherit from QLabel instead of QWidget, converted the QImage to a QPixmap and passed it to self.setPixmap(). That let me get rid of the paintEvent() function entirely and let QLabel handle the painting, which is probably more efficient anyway.

Showing all pages in a scrolled widget

renderToImage gives you one image corresponding to one page of the PDF document. More often, you'll want to see the whole document laid out, with all the pages. So you need a way to stack a bunch of widgets vertically, one for each page. You can do that with a QVBoxLayout on a widget inside a QScrollArea.

I haven't done much Qt5 programming, so I wasn't familiar with how these QVBoxes work. Most toolkits I've worked with have a VBox container widget to which you add child widgets, but in Qt5, you create a widget (no particular type -- a QWidget is enough), then create a layout object that modifies the widget, and add the sub-widgets to the layout object. There isn't much documentation for any of this, and very few examples of doing it in Python, so it took some fiddling to get it working.

Initial Window Size

One last thing: Qt5 doesn't seem to have a concept of desired initial window size. Most of the examples I found, especially the ones that use a .ui file, use setGeometry(); but that requires an (X, Y) position as well as (width, height), and there's no way to tell it to ignore the position. That means that instead of letting your window manager place the window according to your preferences, the window will insist on showing up at whatever arbitrary place you set in the code. Worse, most of the Qt5 examples I found online set the geometry to (0, 0): when I tried that, the window came up with the widget in the upper left corner of the screen and the window's titlebar hidden above the top of the screen, so there's no way to move the window to a better location unless you happen to know your window manager's hidden key binding for that. (Hint: on many Linux window managers, hold Alt down and drag anywhere in the window to move it. If that doesn't work, try holding down the "Windows" key instead of Alt.)

This may explain why I've been seeing an increasing number of these ill-behaved programs that come up with their titlebars offscreen. But if you want your programs to be better behaved, it works to self.resize(width, height) a widget when you first create it.

The current incarnation of my PDF viewer, set up as a module so you can import it and use it in other programs, is at qpdfview.py on GitHub.

Tags: , ,
[ 19:01 Apr 27, 2018    More programming | permalink to this entry | comments ]

Sun, 24 Dec 2017

Saving a transparent PNG image from Cairo, in Python

Dave and I will be giving a planetarium talk in February on the analemma and related matters.

Our planetarium, which runs a fiddly and rather limited program called Nightshade, has no way of showing the analemma. Or at least, after trying for nearly a week once, I couldn't find a way. But it can show images, and since I once wrote a Python program to plot the analemma, I figured I could use my program to generate the analemmas I wanted to show and then project them as images onto the planetarium dome.

[analemma simulation] But naturally, I wanted to project just the analemma and associated labels; I didn't want the blue background to cover up the stars the planetarium shows. So I couldn't just use a simple screenshot; I needed a way to get my GTK app to create a transparent image such as a PNG.

That turns out to be hard. GTK can't do it (either GTK2 or GTK3), and people wanting to do anything with transparency are nudged toward the Cairo library. As a first step, I updated my analemma program to use Cairo and GTK3 via gi.repository. Then I dove into Cairo.

I found one C solution for converting an existing Cairo surface to a PNG, but I didn't have much luck with it. But I did find a Python program that draws to a PNG without bothering to create a GUI. I could use that.

The important part of that program is where it creates a new Cairo "surface", and then creates a "context" for that surface:

surface = cairo.ImageSurface(cairo.FORMAT_ARGB32, *imagesize)

cr = cairo.Context(surface)

A Cairo surface is like a canvas to draw on, and it knows how to save itself to a PNG image. A context is the equivalent of a GC in X11 programming: it knows about the current color, font and so forth. So the trick is to create a new surface, create a context, then draw everything all over again with the new context and surface.

A Cairo widget will already have a function to draw everything (in my case, the analemma and all its labels), with this signature:

    def draw(self, widget, ctx):

It already allows passing the context in, so passing in a different context is no problem. I added an argument specifying the background color and transparency, so I could use a blue background in the user interface but a transparent background for the PNG image:

    def draw(self, widget, ctx, background=None):

I also had a minor hitch: in draw(), I was saving the context as self.ctx rather than passing it around to every draw routine. That means calling it with the saved image's context would overwrite the one used for the GUI window. So I save it first.

Here's the final image saving code:

   def save_image(self, outfile):
        dst_surface = cairo.ImageSurface(cairo.FORMAT_ARGB32,
                                         self.width, self.height)

        dst_ctx = cairo.Context(dst_surface)

        # draw() will overwrite self.ctx, so save it first:
        save_ctx = self.ctx

        # Draw everything again to the new context,
        # with a transparent instead of an opaque background:
        self.draw(None, dst_ctx, (0, 0, 1, 0))  # transparent blue

        # Restore the GUI context:
        self.ctx = save_ctx

        dst_surface.write_to_png("example.png")
        print("Saved to", outfile)

Tags: , , , , ,
[ 19:39 Dec 24, 2017    More programming | permalink to this entry | comments ]
